中华临床医师杂志(电子版) ›› 2025, Vol. 19 ›› Issue (04) : 277 -283. doi: 10.3877/cma.j.issn.1674-0785.2025.04.006

临床研究

CleanerTM旋转式血栓清除系统在下肢深静脉血栓中的临床应用
杨建平, 唐加热克, 管圣()
  1. 830001 乌鲁木齐,新疆维吾尔自治区人民医院血管外科
  • 收稿日期:2025-04-05 出版日期:2025-04-15
  • 通信作者: 管圣
  • 基金资助:
    自治区自然科学基金项目(2024D01C93); 院内项目(20240201)

Clinical application of CleanerTM rotary thrombus removal system in lower extremity deep vein thrombosis

Jianping Yang, Tangjiareke, Sheng Guan()

  1. Department of Vascular Surgery, People’s Hospital of Xinjiang Uygur Autonomous Region, Urumqi 830001, China
  • Received:2025-04-05 Published:2025-04-15
  • Corresponding author: Sheng Guan
引用本文:

杨建平, 唐加热克, 管圣. CleanerTM旋转式血栓清除系统在下肢深静脉血栓中的临床应用[J/OL]. 中华临床医师杂志(电子版), 2025, 19(04): 277-283.

Jianping Yang, Tangjiareke, Sheng Guan. Clinical application of CleanerTM rotary thrombus removal system in lower extremity deep vein thrombosis[J/OL]. Chinese Journal of Clinicians(Electronic Edition), 2025, 19(04): 277-283.

目的

CleanerTM旋转式血栓清除系统是一种新型的血栓清除设备,本文探讨其在髂-股静脉血栓形成(I-FVT)的临床应用及安全性。

方法

本研究选取新疆维吾尔自治区人民医院2021年3月~ 2022年2月经下肢彩色多普勒超声确诊为I-FVT且使用CleanerTM旋转式血栓清除系统治疗的15例患者作为研究对象。收集的临床资料包括术前术后彩超、术中影像、双下肢(膝上、膝下15 cm处)周径、围手术期并发症,随访期血栓复发及血栓后综合征发生情况等。利用术中影像及下肢彩超评估静脉管腔通畅度,患肢与健肢周径差减少程度来评价疗效。

结果

15例I-FVT患者中13例仅行CleanerTM旋转式血栓清除治疗,2例术中辅助大口径导管抽吸击碎的残余血栓碎屑,造影显示Ⅲ级血栓清除13例(86.7%)、Ⅱ级2例(13.3%),平均失血量(28.0±15.2)ml,3例左侧髂静脉植入支架,无器械相关的不良事件,无大出血、有症状肺栓塞等并发症发生。术后48 h患肢与健肢膝上15 cm处肢体周径减少(5.07±2.18 vs 0.64±1.58)cm,膝下周径减少(3.02±1.30 vs 0.52±0.89)cm,差异均具有统计学意义(P<0.05)。24个月随访中无血栓复发、PTS发生,Villalta评分平均为(1.33±0.23)。

结论

经皮机械性CleanerTM旋转式血栓清除系统可适应不同直径的下肢静脉管腔、迅速清除血栓、减少血栓残余,避免导管溶栓相关的风险,是一种安全、有效的血栓清除方法。

Objective

To assess the clinical application and safety of the CleanerTM rotary thrombus removal system, a novel thrombus removal device, in iliac-femoral venous thrombosis (I-FVT).

Methods

In this study, 15 patients who were diagnosed with I-FVT by lower limb color Doppler ultrasonography and treated with the CleanerTM rotary thrombus removal system in the People's Hospital of Xinjiang Uygur Autonomous Region from March 2021 to February 2022 were included. The clinical data collected included preoperative and postoperative color ultrasound images, intraoperative images, circumference of both lower limbs (15 cm above and below the knee), perioperative complications, recurrence of thrombosis and post-thrombotic syndrome during follow-up, etc. Intraoperative imaging and lower limb color ultrasound were used to evaluate the patency of venous lumen and the reduction of the circumference difference between the affected and healthy limbs to evaluate the curative effect.

Results

Among the 15 patients with I-FVT, 13 only received CleanerTM rotary thrombolectomy, and 2 had residual thromboclastic debris crushed by assisted large-diameter catheter aspiration. Angiography showed that 13 cases (86.7%) of grade Ⅲ thromboli and 2 cases (13.3%) of grade II were cleared, with an average blood loss of (28.0±15.2) ml. In 3 patients with left iliac vein stent implantation, no device-related adverse events, major bleeding, symptomatic pulmonary embolism, or other complications occurred. Forty-eight hours after surgery, both the limb circumference at 15 cm above the knee (5.07±2.18 cm vs 0.64±1.58 cm) and that below the knee (3.02±1.30 cm vs 0.52±0.89 cm) decreased significantly (P<0.05). There was no recurrence of thrombosis or PTS during the 24-month follow-up, and the average Villalta score was (1.33±0.23).

Conclusion

The percutaneous mechanical CleanerTM rotary thrombus removal system is a safe and effective thrombus removal method, which can be adapted to different diameters of lower limb venous lumen, quickly remove thrombus, reduce residual thrombus, and avoid the risks associated with catheter thrombolysis.

表1 15例患者一般临床资料
图1 CleanerTM旋转式血栓清除及造影图像。图a为CleanerTM导管未工作状态;图b为CleanerTM导管工作状态;图c为血栓清除后造影
表2 15例患者血栓清除程度[例(%)]
表3 患肢与健肢周径差改变及血栓分布评分比较
表4 15例患者患肢肿胀改善程度[例(%)]
表5 24个月内随访情况
1
中国医师协会介入医师分会, 中华医学会放射学分会介入专业委员会, 中国静脉介入联盟. 下肢深静脉血栓形成介入治疗规范的专家共识(第二版) [J]. 中华介入放射学电子杂志, 2018, 6(4): 283-288.
2
Chopard R, Albertsen IE, Piazza G. Diagnosis and treatment of lower extremity venous thromboembolism: a review [J]. JAMA, 2020, 324(17): 1765-1776.
3
Haig Y, Enden T, Grøtta O, et al. Post-thrombotic syndrome after catheter-directed thrombolysis for deep vein thrombosis (CaVenT): 5-year follow-up results of an open-label, randomised controlled trial [J]. Lancet Haematol, 2016, 3(2): e64-71.
4
Kakkos SK, Goehl M, Baekgaard N, et al. Editor's choice-European Society for Vascular Surgery (ESVS) 2021 clinical practice guidelines on the management of venous thrombosis [J]. Eur J Vasc Endovasc Surg, 2021, 61(1): 9-82.
5
Guanella R, Kahn SR. Post-thrombotic syndrome current prevention and management strategies [J]. Expert Rev Cardiovasc, 2012, 10(12): 1555-1566.
6
Vedantham S. Interventional therapy for venous thromboembolism [J]. J Thromb Haemost, 2015, 13(suppl 1): S245-S251.
7
Vedantham S, Kahn SR, Goldhaber SZ, et al. Endovascular therapy for advanced post-thrombotic syndrome: Proceedings from a multidisciplinary consensus panel [J]. Vasc Med, 2016, 21(4): 400-407.
8
Abramowitz S, Shaikh A, Mojibian H, et al. Comparison of anticoagulation vs mechanical thrombectomy for the treatment of iliofemoral deep vein thrombosis [J]. J Vasc Surg Venous Lymphat Disord, 2024, 12(4): 101825.
9
White RH. The epidemiology of venous thromboembolism [J]. Circulation, 2003, 107(23 suppl 1): I4-I8.
10
何楠, 唐小斌, 梁紫轲, 等. 一站式腔内治疗急性深静脉血栓形成合并髂静脉压迫综合征的临床价值 [J]. 中华血管外科杂志, 2023, 8(2): 187-192.
11
Huan KWSJ, Tan CS, Chua D, et al. The cleaner XT™ device as an endovascular adjunct for pharmacomechanical thrombolysis of thrombosed arteriovenous fistulas and grafts [J]. Ann Vasc Dis, 2020, 13(4): 390-396.
12
Webb AH, Zacharias K, Ciowlek P, et al. Utility of rotational thrombectomy for the management of thrombosed arteriovenous shunts [J]. The Arab Journal of Interventional Radiology, 2020, 4: S7.
13
Bozkurt A, Kırbaş İ, Kösehan D, et al. Pharmacomechanical thrombectomy in the management of deep vein thrombosis using the cleaner device: an initial single-center experience [J]. Ann Vasc Surg, 2015, 29(4): 670-674.
14
Köksoy C, Yilmaz MF, Başbuğ HS, et al. Pharmacomechanical thrombolysis of symptomatic acute and subacute deep vein thrombosis with a rotational thrombectomy device [J]. J Vasc Interv Radiol, 2014, 25(12): 1895-1900.
15
Calik ES, Dag O, Kaygin MA, et al. Pharmacomechanical thrombectomy for acute symptomatic lower extremity deep venous thrombosis [J]. Heart Surg Forum, 2015, 18(4): E178-183.
16
Bozkurt A, Kirbas I, Kosehan D, et al. Pharmacomechanical thrombectomy in the management of deep vein thrombosis using the cleaner device: an initial single-center experience [J]. Ann Vasc Surg, 2015, 29(4): 670-674.
17
Yuksel A, Tuydes O. Midterm outcomes of pharmacomechanical thrombectomy in the treatment of lower extremity deep vein thrombosis with a rotational thrombectomy device [J]. Vasc Endovascular Surg, 2017, 51(5): 301-306.
18
赵洁, 陈江浩. CleanerTM旋转式血栓清除系统、AngioJet血栓清除系统及Straub血栓清除系统在下肢深静脉血栓形成中的应用效果及安全性 [J]. 实用心脑肺血管病杂志, 2022, 30(4): 78-83.
19
崔风强, 陈江浩, 袁时芳, 等. Cleaner血栓清除系统联合导管接触性溶栓治疗急性下肢深静脉血栓的近期疗效观察 [J]. 中国血管外科杂志(电子版), 2023, 15(2): 128-131.
20
杨建平, 宋巍, 慈红波, 等. 机械性血栓清除联合置管溶栓在治疗急性髂-股静脉血栓形成的临床分析 [J]. 新疆医学, 2017, 47(11): 1254-1257.
21
杨建平, 慈红波, 方青波, 等. 不同方式治疗急性深静脉血栓形成的临床效果和安全性[J/OL]. 中华临床医师杂志(电子版), 2019, 13(10): 721-725.
22
Song XJ, Liu ZL, Zeng R, et al. The efficacy and safety of AngioJet rheolytic thrombectomy in the treatment of subacute deep venous thrombosis in lower extremity [J]. Ann Vasc Surg, 2019, 58: 295-301.
23
Zhu YF, Li LB, Liu ZJ, et al. Single-stage treatment of AngioJet rheolytic thrombectomy and stenting for iliac vein compression syndrome with secondary acute iliofemoral deep vein thrombosis [J]. Ann Vasc Surg, 2019, 61: 384-393.
24
Shen Y, Wang X, Jin SS, et al. Increased risk of acute kidney injury with percutaneous mechanical thrombectomy using AngioJet compared with catheter-directed thrombolysis [J]. J Vasc Surg Venous Lymphat Disord, 2019, 7(1): 29-37.
25
李云松, 刘向东, 李亮, 等. AngioJet血栓抽吸术在机械血栓清除联合置管溶栓治疗急性下肢深静脉血栓中的价值 [J]. 中华普通外科杂志, 2019, 34(6): 509-511.
26
史亚东, 顾建平, 陈亮, 等. Straub Aspirex结合置管溶栓对比单纯置管溶栓治疗下肢深静脉血栓的研究 [J]. 临床放射学杂志, 2018, 37(11): 1916-1921.
27
张温温, 孙灿龙. Straub血栓清除系统与人工血栓抽吸治疗急性下肢深静脉血栓形成的效果比较 [J]. 中国实用医刊, 2021, 48(19): 5-8.
28
Köksoy C, Yilmaz MF, Başbuğ HS, et al. Pharmacomechanical thrombolysis of symptomatic acute and subacute deep vein thrombosis with a rotational thrombectomy device [J]. J Vasc Interv Radiol, 2014, 25(12): 1895-1900.
